Orange Smooth Polyurethane Round Belt PU Round Belt SGS ISO9001: 2008 Certified Diameter 2-20mm

  • Orange Smooth Polyurethane Round Belt PU Round Belt SGS ISO9001: 2008 Certified Diameter 2-20mm
Cantidad de orden mínima 1.000
Precio 0.5

Éntreme en contacto con gratis las muestras y los vales.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

Si usted tiene alguna preocupación, proporcionamos ayuda en línea de 24 horas.

x
Datos del producto
Modelo No. Dia 2 mm-20 mm Tipo Correa de la ronda de la PU
Material PUS Material interno PUS
Superficie Liso o áspero Resistencia a la tracción 55N/mm2
Diámetro 2 ~ 20 mm Dureza 85 a ~ 90 a
estirar tarifa 1.5-3% Mínimo radio 20 a 160 mm
Máxima tracción 0.3-31.3 kg Longitud de rollo 30-400 m
Resistencia a la abrasión Pendiente Fuerza de la lágrima Alto
Resistencia al impacto Alto
Resaltar

SGS ISO9001: 2008 Certified Polyurethane Round Belt

,

Diameter 2-20mm PU Round Belt

,

Orange Polyurethane Round Belt
Deja un mensaje
Descripción de producto
Orange Smooth Polyurethane Round Belt

Our premium Polyurethane round belts are designed for transmission applications in industrial machinery and product conveyance systems. These belts feature a durable poly cord construction and are available with both smooth and rough surfaces to suit various operational requirements.

Product Features
  • Outstanding abrasion resistance
  • High tensile and tear strength
  • Resistance to oils, fuels, and oxygen
  • Excellent weatherability and high impact resistance
  • Low compression set for long-term performance
  • Available with polyester, nylon, or fiber reinforcement
  • Can be welded to form O-rings
Applications

Ideal for use in:

  • Newspaper conveying systems
  • Packaging machinery
  • Ceramic and stoneware processing plants
  • Floor and roof tile conveyance
  • Wood working machinery
  • Textile machines
  • Paper industry equipment
  • Food grading and processing machines
Technical Specifications
Items NO. Φ Least Radius of Gyration Stretching Rate Maximum Tensile Rate Hardness Length of Roll
DIA(mm) In mm % Kg Lbs Shore(A) Roll(m)
2mm 0.79 20 1.5-3% 0.3 0.7 95 400
2.5mm 0.87 22 1.5-3% 0.4 0.9 95 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 400
3.5mm 1.18 30 1.5-3% 0.95 2.1 90 400
4mm 1.38 35 1.5-3% 1.2 2.7 90 200
5mm 1.57 40 1.5-3% 2 4.3 90 100
6mm 1.97 50 1.5-3% 3.2 7 90 100
7mm 2.17 55 1.5-3% 4.1 9 90 100
8mm 2.56 65 1.5-3% 5 11 90 100
9mm 2.95 75 1.5-3% 6.8 15 90 50
10mm 3.94 100 1.5-3% 7.7 17 90 50
12mm 3.94 100 1.5-3% 12.2 27 90 30
15mm 4.72 120 1.5-3% 17.7 39 90 30
18mm 5.71 145 1.5-3% 25.4 56 90 30
20mm 6.3 160 1.5-3% 31.3 69 90 30

Note: We also supply connecting tools and accessories for polyurethane belts, including clamps, electric irons, and knives. Connection methods include hot press welding and overlap welding.
